10,000 LBS OF COMPACTION FORCE TO CONQUER MEDIUM - LARGE JOBS QUICKLY

The BR4600 Reversible Compactor is built for medium and large applications. Equipped with a Honda GX390, it has the power and force to effectively compact deep base material properly.

Features

  • Hydraulic reversing mechanism with flexible maneuverability allows the machine for forward, backward, and spot-on compaction
  • Cast aluminum throttle lever for a more professional, stronger, and durable for tamping
  • New closed style frame for increased engine and guide hook protection
  • Cast aluminum belt cover for increased clutch and engine longevity
  • Ductile iron bases for increased strength and durability
  • Optional extension plates and urethane mat options available

OPTIONS:

BR4600H 19" (48cm) x 34" (86cm) plate, GX390 Honda, 10,120lbs/4,600kg centr. force

BR4600HE 25" (62cm) x 34" (86cm) plate, GX390 Honda, 4,600kg c. Force, c/w ext kit (# 651111)

BR4600Y 19" (48cm) x 34" (86cm) plate, Yanmar L100 Diesel, Elec.Start 4,600kg centr. force

BR4600YE 25" (62cm) x 34" (86cm) plate, Yanmar Elec.Start, 4,600kg Force, c/w ext kit (# 651111)

Specs

Engine Type Honda GX390 Yanmar L100W
Power Output 11.7hp (8.7kW) 9.3hp (6.9kW)
Compaction Force 10141 lbf, 45kN, 4600 kgf
Max Travel Speed 72'/min (22m/min)
Length 62" (157cm)
Width 19" (48cm)
Height 37" (93cm)
Weight 672 lbs (305kg) 719 lbs (326kg)
Plate Size 19" x 34" (49cm x 86cm)
